Stredovýšková 3-pásmová sústava má označenie COBRA-4-TOP.
Je osadená 15"basovým reproduktorom EVX155, 4 kusmi C8 a vyskovym driverom EV DH2T.
Na bočných stenách sú osadené ANCRA závesné elementy.
Cabinet: MID - HIGH Cabinet
Configuration: Compact line array / active 3-way
Nominal impedance: LOW - MID - HIGH: 8 Ohms - 8 Ohms - 8 Ohms
Rated power RMS: LOW - MID - HIGH: 400 W - 200 W - 200 W
Program power: LOW - MID - HIGH: 800 W - 400 W - 400 W
SPL 2,83 V / 1m 1 W / 8 Ohm: 100 dB
Max. SPL 1m (calculated): 131 dB
Frequency response ( -10dB ): 90Hz - 17kHz
measured with DSP 244 preset: COB4TOPFAR200203
Coverage angle 1 kHz (-6dB): H 120° x V 30°
Coverage angle 10kHz (-6dB): H 90° x V 5°
Active crossover frequency: 124Hz - 700Hz - 4kHz
Voice coil tracking protection : LOW - MID - HIGH
Components HIGH: DH 2T Line array
Components MID: C8 Line array
Components LOW: EVX155
Connector wiring HIGH: 8-pole 4+/4-
Connector wiring MID: 8-pole 3+/3-
Connector wiring LOW: 8-pole 2+/2-
Connector model: Speakon 2x NL8 MPR
Rozmery (WxHxD) mm: 600 x 495 x 717
Váha : 63.5 kg
Dynacord COBRA 4 TOP - Datasheet
